Liftgate Lamp (Remove and Replace)

Correction code 1511010032 FRT 0.12 NOTE: Unless otherwise explicitly stated in the procedure, the correction code and its associated FRT reflect all of the work required to perform this procedure, including the linked procedures. Do not stack correction codes unless explicitly told to do so. NOTE: See Flat Rate Times to learn more about FRTs and how they are created. NOTE: See Personal Protection to make sure you are wearing proper PPE when performing the procedure below. NOTE: See Ergonomic Precautions for safe and healthy working practices.

Remove

  1. Remove the liftgate lower trim. See Liftgate Lower Trim (Remove and Replace).
  2. Use a plastic trim tool to remove liftgate lamp cover from lower trim assembly.
  3. Disconnect liftgate lamp connector.
  4. Remove liftgate lamp from lower trim assembly.

Install

  1. Install liftgate lamp to lower trim assembly.
    Note
    Ensure the liftgate lamp is fully seated.
  2. Connect liftgate lamp connector.
  3. Install the liftgate lamp cover to lower trim assembly.
  4. Install the liftgate lower trim. See Liftgate Lower Trim (Remove and Replace).
