Bumper Beam - Rear (Model Y Standard) (Remove and Install)

Correction code 10011500001 10011500001 FRT 0.60 NOTE: Unless otherwise explicitly stated in the procedure, the correction code and its associated FRT reflect all of the work required to perform this procedure, including the linked procedures. Do not stack correction codes unless explicitly told to do so. NOTE: See Flat Rate Times to learn more about FRTs and how they are created. NOTE: See Personal Protection to make sure you are wearing proper PPE when performing the procedure below. NOTE: See Ergonomic Precautions for safe and healthy working practices.

Torque Specifications

Table 1. Torque Specifications:Bumper Beam - Rear (Model Y Standard) (Remove and Install)
Description Torque Value Recommended Tools Reuse/Replace Notes
Nuts (x6) that attach the rear bumper beam or trailer hitch to the vehicle
60 Nm (44.2 lbs-ft)
  • 6 in extension
  • Ratchet/torque wrench
  • Cordless Ratchet/Impact Driver
  • 15 mm deep socket
  • Torque wrench with angle measurement(for installation only)
 Reuse

Remove

  1. Remove the rear fascia assembly from body. See Fascia - Rear - Upper (Model Y Standard) (Remove and Install).
  2. Remove the nuts (x6) that attach the rear bumper beam to the vehicle.
    Tip
    Use of the following tool(s) is recommended:
    • 6 in extension
    • Ratchet/torque wrench
    • Cordless Ratchet/Impact Driver
    • 15 mm deep socket
    • Torque wrench with angle measurement(for installation only)
    Figure 1. LH shown, RH similar
  3. With assistance, remove the rear bumper beam.

Install

  1. Position the rear bumper beam on the body, and then install the nuts (x6) that attach the rear bumper beam to the vehicle.
    60 Nm (44.2 lbs-ft)
    Tip
    Use of the following tool(s) is recommended:
    • 6 in extension
    • 15 mm deep socket
    Figure 2. LH shown, RH similar
  2. Install the rear fascia and diffuser assembly. See Fascia - Rear - Upper (Model Y Standard) (Remove and Install).
