Sail Applique - LH (Long Range) (Remove and Install)

Correction code NEW NOTE: Unless otherwise explicitly stated in the procedure, the correction code and its associated FRT reflect all of the work required to perform this procedure, including the linked procedures. Do not stack correction codes unless explicitly told to do so. NOTE: See Flat Rate Times to learn more about FRTs and how they are created. NOTE: See Personal Protection to make sure you are wearing proper PPE when performing the procedure below. NOTE: See Ergonomic Precautions for safe and healthy working practices.

Warning
This procedure is a DRAFT. Although it has been validated, Warnings and Cautions might be missing. Follow safety requirements and use extreme caution when working on or near High Voltage systems and components.
  • 2025-06-21: Released new procedure.
  1. Open tailgate
    Note
    Press button to release
  2. Remove LH sail applique
    Note
    15x clips, 1x connector, 1x harness clip, Lift rear edge first to remove connector and harness clip
  3. Install LH sail applique
    Note
    15x clips, 1x connector, 1x harness clip, Replace any broken clips
  4. Close tailgate
