Vehicle and Wheel Paint Codes
Provides paint color and code information for Tesla vehicles and wheels.
Vehicle Paint Codes
The vehicle paint code is printed in the lower left hand corner of the
manufacturing certification label. This label is affixed to the driver’s side door
jamb, except for vehicles in
China, where it is affixed to the passenger's side door jamb.
| Paint Code | Paint Color | Finish |
|---|---|---|
| PPMR | Base Red, Red Multicoat | Tricoat Metallic |
| PBCW | Base White | Solid |
| PPSB | Blue, Deep Blue Metallic, Ocean Blue (2015 and later) | Metallic |
| PMMB | Blue (2012-2015) | Metallic |
| PMAB | Brown (2012-2014) | Metallic |
| PX02 | Diamond Black | Metallic |
| PB800 | Frost Blue Metallic | Metallic |
| PMNG | Gray, Midnight Silver Metallic, Steel Gray (2014 and later) | Metallic |
| PMTG | Gray (2012-2014) | Metallic |
| PMSG | Green (2012-2014) | Metallic |
| PN02 | Lunar Silver | Metallic |
| PMBL | Obsidian Black | Metallic |
| PPSW | Pearl White Multi-Coat | Tricoat Metallic |
| PPSR | Signature Red | Tricoat Metallic |
| PMSS | Silver | Metallic |
| PBSB | Solid Black, Base Black | Solid |
| PN01 | Stealth Gray | Metallic |
| PPTI | Titanium Silver (2015-2017) | Metallic |
| PR01 | Ultra Red | Tricoat Metallic |
2025+ Model S Wheel Paint Codes
| Wheel/Cover Name | Image | Wheel Size | Color Name | Paint Code |
|---|---|---|---|---|
| Magnetite (Wheel) | 19" | Incognito | NEU-285E | |
| Magnetite (Aero Inserts) | 19" | Sierra Black | NEU-105E | |
| Magnetite(Aero Spoke Inserts) | 19" | Sierra Black | NEU-105E | |
| Velarium (Wheel) | 21" | Incognito | NEU-285E | |
| Velarium (Aero Inserts) | 21" | Armor Black | NEU-119E | |
| Velarium (Center Cap) | 21" | Incognito | NEU-285E |
2021+ Model S Wheel Paint Codes
| Wheel/Cover Name | Image | Wheel Size | Color Name | Paint Code |
|---|---|---|---|---|
| Arachnid (Wheel) | 21" | Gunpowder | WPB-82422E | |
| Cardenio (Wheel) | 19" | Magneto Metallic | WPB-82042 | |
| Tempest (Wheel Cover) | 19" | High Gloss Black and Cinder Grey |
3051-025 and 3051-034 |
