Correction code 15302702 15302701 FRT 0.06 NOTE: Unless otherwise explicitly stated in the procedure, the above correction code and FRT reflect all of the work required to perform this procedure, including the linked procedures. Do not stack correction codes unless explicitly told to do so. NOTE: See Flat Rate Times to learn more about FRTs and how they are created. To provide feedback on FRT values, email ServiceManualFeedback@tesla.com. NOTE: See Personal Protection to make sure wearing proper PPE when performing the below procedure. NOTE: See Ergonomic Precautions for safe and healthy working practices.

1. Open liftgate from exterior switch



2. Remove load floor
   Note

   Use pull tab located at rear edge of panel





3. Remove trunk sill trim assembly
   Note

   4x clips, 1x location pin, Pull corner upward release clip on the end the away from body for remaining clips





4. Remove clips securing rear trunk carpet
   Note

   2x push clips



5. Remove rear trunk carpet from vehicle
   Note

   4x velcro strips





6. Install rear trunk carpet into vehicle
   Note

   4x velcro strips, Fully seat carpet at velcro strips





7. Install clips securing trunk carpet
   Note

   2x push clips



8. Install trunk sill trim assembly
   Note

   4x clips, 1x location pin, Align the latch with center slot then 2 locator to their slot and then press to secure the clips, Adjust the seal to overlap the trim









9. Install load floor





10. Close trunk
