Bumper Assembly - Rear (Remove and Replace)

Correction Code 10013102

Removal

  1. Remove the rear fascia (refer to procedure).
  2. Remove the nuts (x8) that secure the rear bumper to the studs on the body (torque 65 Nm).
  3. Remove the rear bumper from the vehicle.

Installation

Installation procedure is the reverse of removal.
