Sensor - Ultrasonic - Rear Door - LH (Remove and Replace)
Correction Code 11334312
- 2023-11-03: Updated ultrasonic sensor temperature for installation.
- 2023-07-21: Updated procedure to latest GSD validation, elevated temperature and pressure values for ultrasonic sensor installation.
Special tools required for this procedure:
Part Number | Description |
1080580-00-A | Heat gun |
1080603-00-A | Infrared thermometer |
1080978-00-A | Force gauge |
1080978-10-A | 22 mm diameter tip for force gauge |
1095806-00-A | Target, Falcon Door Ultrasonic Sensor, MX |
Removal
- Open the LH front door and lower the window.
-
Open the LH rear door to a comfortable working position.
NoteMake sure that the LH rear window is fully closed.
- Remove the lower rear LH door trim garnish. See Garnish - Door Trim - LH - Rear - Lower (Remove and Replace).
- Remove the LH rear door trim panel. See Panel - Door Trim - Rear - LH (Remove and Install).
- Set the LH rear door to a comfortable working position.
- Remove the underhood storage unit. See Underhood Storage Unit (Remove and Replace).
- Remove the HEPA filter. See Filter - HEPA (Remove and Replace).
- Disconnect 12V power. See Disconnect 12V Power.
- Remove the LH rear door closeout panel. See Closeout Panel - Door - Rear - LH (Remove and Install).
-
Twist the cap that holds the
ultrasonic sensor clockwise to remove it, and then remove the spring and
spacer.
NoteWhen the cap (1) is removed, the spring (2) and spacer (3) might fall out of the sensor carrier.
1 Cap 2 Spring 3 Spacer 4 Ultrasonic sensor 5 Carrier 6 Butyl patch -
Release the locking tab,
disconnect LH rear door ultrasonic sensor electrical connector, and then use a
plastic trim tool to remove the sensor fro the sensor carrier.
CAUTIONUse a plastic trim tool to remove the sensor. Do not use a pick, as this can scratch the vehicle paint.NoteInspect the face of the sensor; make sure that the adhesive that affixed the sensor to the door was removed with the sensor. If any adhesive remains stuck to the door, use a plastic trim tool to remove it.NoteDiscard the ultrasonic sensor after removal.
Installation
CAUTION
The ultrasonic
sensor is a one time use component. If the ultrasonic sensor is removed, it must be
discarded and a new ultrasonic sensor must be installed.
- Attach the 22 mm tip to the force gauge.
- Use IPA wipes to thoroughly clean the sensor mounting area on the door panel.
- Use a spring clamp, bar clamp, or similar tool to gently hold the new sensor with the coupling tape facing up.
-
Use an infrared thermometer to
check the temperature of the door panel. If necessary, use the heat gun to heat
the door panel to at least 25°C (77°F).
CAUTIONDo not continue this procedure unless the door panel is at least 25°C (77°F).
- Remove the protective film from the new sensor.
- Use a heat gun and infrared thermometer to heat the new ultrasonic sensor to 40º–50ºC (104°-122ºF).
-
Install the ultrasonic sensor
onto the LH rear door panel.
CAUTIONWear appropriate PPE to prevent personal injury.
- Use the force gauge to apply a force of 65 N to the sensor for at least 30 seconds.
-
Reinstall the spacer, spring, and
cap to secure the ultrasonic sensor.
NoteWhen reinstalling the spacer, ensure that the flat side faces the sensor.
-
Connect the electrical connector
to the new ultrasonic sensor, and then attach the harness clip to the ultrasonic
sensor carrier.
- Install the LH rear door closeout panel. See Closeout Panel - Door - Rear - LH (Remove and Install).
- Connect 12V power. See Disconnect 12V Power.
- Press and hold the close button on the LH B-pillar until the LH rear door fully latches.
-
Position the ultrasonic sensor
target special tool approximately 60 cm out from the center of the LH rear
door.
-
Attach the cap of the target tool
long cable over the rear bolt of the front lifting pad under the vehicle.
-
Attach the cap of the target tool
short cable over the front bolt of the rear lifting pad under the vehicle.
-
Reposition the target tool so
both cables are taut, and then move the target tool cable ring up to just above
the marker.
- Connect a laptop to the diagnostic port of the vehicle, and then use Toolbox 3 to locally connect to the vehicle. See Toolbox 3 (Connect and Disconnect).
- Unlock the vehicle gateway for diagnostic communication. See Gateway Unlock.
-
Select the door to be
tested:
- For the driver side rear door, in Toolbox 3, click the Actions tab, type "DRV_USS_DOOR" into the search field, click TEST-SELF_BCFALCD_DRV_USS-DOOR-WITH-OBSTACLEvia Toolbox: (link), click Run, and allow the routine to complete.
- For the passenger side rear door, in Toolbox 3, click the Actions tab, type "PAS_USS_DOOR" into the search field, click TEST-SELF_BCFALCP_PAS_USS-DOOR-WITH-OBSTACLEvia Toolbox: (link), click Run, and allow the routine to complete.
- Disconnect the laptop from the vehicle. See Toolbox 3 (Connect and Disconnect).
- Install the LH rear door trim panel. See Panel - Door Trim - Rear - LH (Remove and Install).
- Install the lower rear LH door trim garnish. See Garnish - Door Trim - LH - Rear - Lower (Remove and Replace).
- Install the HEPA filter. See Filter - HEPA (Remove and Replace).
- Install the underhood storage unit. See Underhood Storage Unit (Remove and Replace).
- Use the touchscreen to calibrate the rear doors via .
