Torque Specifications - Infotainment

Table 1. Torque Specifications: Chime - Power Trunk (Remove and Replace)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Screws that attach the chime to the power trunk lid trim	2.3 Nm (1.7 lbs-ft)	Torx T20 socket 4 in extension Ratchet/torque wrench	Reuse

Table 2. Torque Specifications: Speaker - Front Door - LH (Remove and Replace)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Screws that attach the front door speaker to the door	4 Nm (2.9 lbs-ft)	8 mm socket ¼ in std ratchet ¼ in torque wrench (installation only) 2 in extension	Reuse

Table 3. Torque Specifications: Touchscreen (Remove and Replace)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Display housing to touchscreen fasteners	3 Nm (2.2 lbs-ft)	Torx T30 socket ¼ in std ratchet ¼ in torque wrench (installation only) 2 in extension	Replace
Instrument panel to touchscreen fasteners (10mm hex)	16 Nm (11.8 lbs-ft)	10 mm socket ¼ in std ratchet ¼ in torque wrench (installation only) 4 in extension	Replace
Instrument panel to touchscreen fastener (T30 Torx)	12 Nm (8.8 lbs-ft)	Torx T30 socket ¼ in std ratchet ¼ in torque wrench (installation only) 4 in extension

Table 4. Torque Specifications: USB Hub - Center Console - Front (Remove and Replace)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Bolts that attach the USB hub to the center console	1.1 Nm (.8 lbs-ft)	Torx T20 socket 4 in extension	Reuse

Table 5. Torque Specifications:

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
